Switches & Lights
STAR-control CAN plus Wireless 8 x 35A Channel Controller
$544.55 ( $599.00 inc GST )
STAR-light CAN wired and Bluetooth Wireless 8 Channel LED Controller
$335.45 ( $369.00 inc GST )
STAR-light Wireless Battery 4 Button Switch Alloy Housing
$212.73 ( $234.00 inc GST )
STAR-light Wired 4 Button Switch Alloy Housing
$212.73 ( $234.00 inc GST )
Classic Switch Module Labels: Select from 50 Engraved Buttons Available
$125.45each ( $138.00 inc GST )
Safiery Dimmable Alloy Switch 2 buttons Dual Colour Compatible LED Custom Engraved
$101.36 ( $111.50 inc GST )
Gas Strut Switch for Automatic Lighting Control
This gas strut switch wires into the positive circuit for canopy door lights so that they come on automatically when opened. The switch is designed to close the circuit when it is opened and open the circuit when closed. It takes less than a few minutes to install on gas strut.
This is perfect for canopy doors to have "auto" light on when doors are opened.
Simply wire the positive wire through the gas strut switch. Turn the light switch on and "hey presto" when the door is opened, the light come on.
There is a significant discount for volume purchases.
Classic Switch Labels are Pre-printed
SELECTED LABELS TO CHOOSE FROM FOR INSTANT SHIPPING.Â
COMPARISON OF CLASSIC AND SMART SWITCH
| Â | Classic Switch | Smart Switch |
| Alloy Body in Matt Black or Satin Silver | Yes | Yes |
| 4 Channel Switch that latches on when pressed | Yes | Yes |
| Switch Dims as you hold the button | Yes | Yes |
| Double press button turns LED high at any tme | No | Yes |
| Momentary Outputs instead of latched outputs (raise lower, in/out control) | No | Yes |
| Operates Devices like Pumps, heater control, LED light bars | Yes | Yes |
| Dual Control from two identical switches to one set of 4 channel outputs | No | Yes |
| Can be operated by Remote Key Fob up to 40M away without any other devices | No | Yes |
| Electrical Connection to devices to be switched | At the switch rear Plug 1 x 8A and 3 x 2A | At the Smart IO Board connected by RJ45 cable 2 x 10A , 1 x 5A , 1 x 2A |
Â
SMART SWITCH: PLUG CONNECTED 4 CHANNEL SWITCH ON/OFF for PUMPS, DEVICES and DIMMABLE for LED LIGHTING SECURE WIRELESS MESH READY FOR REMOTE CONTROL
Row of Smart Switches in Expedition Vehicle
Each Smart IO controls up to 4 channels for swing control, device power and Lights
SMART SWITCH INSTALL: Easy as 1-2-3
- Install the Smart Switch on the dash/ console. Install the Smart I/O Board close to the point of action.
- Connect an RJ45 Cat5 cable into the Switch at rear and Smart I/O Board. (Using the 4 pair of wires, not using as a data cable)
- Wire the devices to be controlled direct to Smart I/O Board outputs.
NO Programming required:
- Out of the box installation
- Can be added to with additional modules at a later date
- Affordable package of around $330 retail for Switch and SmartI/O and Wireless Ready.
The Backlit Easy Touch panel:
- 4 Channel Switch
- Backlit LED comes on when output is turned on (not just because it is touched)
- Dims the LED lights and holds the dimmable value in memory so when the light is turned on again, it returns to the last dimmable memory position.
- Surround trim compliments Simarine Pico Display
Matt Finished Alloy Slimline 4 Channel Switch ON/OFF for PUMPS, DEVICES and DIMMABLE for LED LIGHTING
The Backlit Classic Switch:
- 1 x 8A (Top Left) Non Dimmable and 3 x 2A Dimmable channels.
- Alloy switch body
- Matt Black or Satin Silver
- Surround trim compliments Simarine Display
- 4 Channel Switch
- Backlit LED turns blue when touched
- Haptic Feedback when touched
- Backlight display can be turned off for perfect "no light at night"
Two Model Variations:
- Select from our list of Engraved Labels.
- Custom Engraved Labels: Two lines, 7 characters per line.
Easy to Install
- Fit into cut-out with either Spring Clips or C-bracket if you can access behind switch.
- Wire 12V Power to switch
- Wire the devices to be controlled direct to Switch
NO Programming required:
- Out of the box installation
- Dim LED's out of box
- Affordable package
The Classic Switch has:
- One x 8A Channel (TOP LEFT BUTTON ALWAYS) and Three x 2A Dimmable Channels for LED's
- Supply 12V Positive power directly if required.
