Lifestyle for Patrol: Drawers, Induction, 30L Fridge, 600Ah Lithium 3000W Inverter/Charger Scotty 15

This is for latest model for LC300 and for Nissan Patrol

Note for those comparing Redarc’s award winning Redvision Manager30 Kit (Trademark Redarc), the Safiery Black Bridge pack outstrips this kit with:

BIGGER screen but takes less space : 157 x 82 x 25 compared to 178 x 108 x 26
Alloy and Gorilla Glass Display – no plastic nor equivalents
Colour high resolution display – no pixelated screen
8 dedicated buttons – no screen to touch to pre-select
Custom engraved alloy buttons, words or icons – no single letter guesses
Optional Inclinometer plug n play option – no separate system and app
Victron 5000VA Inverter/Charger has Storage Mode for Lithium
Victron Bluetooth Control 20A Solar Charger with 30 day history (30A, 50A option)
Alloy base single control module with on board fuses and 12 input/outputs for switch connections
Warranty 5 years Victron and 3 years Simarine – compare to 2 years

Desktop Comparison from Website	Redarc Redvision & Manager30 (trademark)	Safiery Black Bridge
Operating Temperature (Distribution box)	-20°C to + 60°	-10°C to + 70°’
Operating Temperature (Display)	-20°C to + 70°C	-10°C to + 70°’
Storage Temperature (Display)	-20°C to + 85°C	-10°C to + 70°’
Maximum Charger Current	40A	50A
Maximum Battery Current	80A	100A
Temperature Sensors	2	Up to 4
Output Circuits (Max)	5 x 10A	2 x 20A, 2 x 15X, 2 x 10A
Output Circuits (Max)	5 x 30A	12 direct connected crcuits
Main Unit Dimensions	385 x 138 x 58mm	200 x 160 x 42 mm
Display Dimensions	178 x 108 x 26mm	157 x 82 x 25 mm
Warranty	2 Years	3 years
Output System Voltage	12VDC	12V
Maximum Charging Voltage	16.0V* (*Calcium setting in storage mode)	16V
Output Current Rating (Cont.)	30A	50A
Output Power	520W	600W
Input Fuse Rating	40A
Output Fuse Rating	40A	30A, 20A
Warranty	2 Years	5 Years Victron, 3 years Simarine
Protection	Short Circuit, Surge, Reverse Polarity, Overload	Short Circuit, Surge, Reverse Polarity, Overload
Input (Operating) Voltage	240VAC / 9 – 32VDC	240VAC / 9 – 32VDC
Weight (kg)	7.8 kg Total	5.4kg total
AC Mains Plug Type	AU, NZ, EU	AU
Type Approval	CE	CE, AU
