This navigation does not require the internet. (like Apple Carplay does)
Get Camper-specific Garmin navigation with hands-free voice control,
Camper routing that matches your rig, driver alerts and points of interest.
Sets up your Vehicle and Van Profiles
Set up your trip before leaving home.
Keeps a History of your trip.
Enabling or Disabling Driver Alerts
Red light and speed cameras
Navigate to your destination
Select Routes on the map... Plus much more...
Award Winning HEMA Locations - built for Camping
Australian maps with HEMA integration: they can be incorporated into your travel plan BEFORE you leave.
There is no need for the internet (like Apple or Google Maps).
The locations are all stored inside the head unit. Here is the category list from HEMA.
Award Winning FUSION Sound System
Music Playback and Stereo Features
Radio, Bluetooth Streaming, Apple Airplay, USB, Android, UPnP.
4 Zones ready for Speakers
Suggest 2 Zones in Canopy/ Camper; 2 Zones in Cab
Control Volume by Zone
Adjust Tones by Zone
Attach a Subwoofer
Digital Signal Processing (DSP)
Muting all Connected Stereos
Automatic Volume Adjustment Based on Speed
USB Device Playback Control
Optional 4 Speaker Package for FUSION Sound System
Packaged in Black or White
Outdoor Speakers are IP65.
4 Zones to suit Speakers
Suggest 2 Zones in Canopy/ Camper; 2 Zones in Cab
OR 2 Zones inside/ 2 Zones outside in Caravan
Control Volume by Zone
Adjust Tones by Zone
Rated at 100W per speaker
Digital Signal Processing (DSP)
Frequency Response of 67 Hz - 20 kHz
431 x 171 mm
41mm Deep
Can have optional spacer for surface mounting.
Award Winning IP Cameras
While up to 4 RCA cameras can be connected,
The power of cameras is with IP cameras. They are inexpensive and higher resolution.
The optional modem router is required for the IP Cameras.
IP Cameras can be visible on your Smartphone connected to the local WiFi
IP Cameras can also be visible through the internet when away from the Van or Vehicle for remote viewing of activity.
Award Winning TPMS & Airbag Automation
Tyre Pressure AND Temperature is critical to monitor in a big trip.
Just add the External Sensor on the Tyre Inflator stem
Configure each cap to its location.
Water resistant.
Replaceable sensor batteries.
Sensors transmit pressure and temperature data every 5 minutes.
Fast leakage alert.
Airbag control at touch of button
See Pitch and Roll on Screen
External Keypad with user Settable PIN to Activate
CAN bus switch panel means only 2 data wires and power instead of 40 to traditional switch panel (3 LED status/switch)
8 programmable buttons but first 4 kept for PIN
Button show led, running and alarm indication which can be dynamic (led colors: orange, orange, red)
Customized text for user designed switches
Buttons are backlight for night time operation
Durability & robustness IP67 means designed for harsh environment.
UV stable means designed for outdoor mounting
World Exclusive User Customisation Included in Licence
User can set their own PIN code for external switch activation.
User can select which channels are activated for up to 4 modes
User can select which channels the external 8 button switch activates.
User can select which channels the internal 4 button smart switch activates.
User can calibrate or recalibrate the water tanks.
Overview
Safiery’s Integrated Display is both integrated “hardware” and integrated “software”:
Uses the GARMIN 8 /10 inch high resolution Display using Safiery software connecting to FOUR MODULES for RV’s.
Software is compiled binary code and can’t be replicated from the installed system.
There is close to 1,000 hours of software and hardware development in this system. The business model is that this standard software is included in the End User Licence Agreement when a complete package is purchased from Safiery. It is licenced software and not available for sale as a separate software or a separate GARMIN system.
Garmin Vieo Head Unit
Garmin Navigation with accurate GPS – Australian maps with downloadable updates and no internet needed
Garmin "Where to" Map Database – no internet needed
Hema Guides: Camping Grounds etc – no internet needed
Smartphone integration for calls and contact database
Digital Audio Band (DAB) Radio – digital radio of the future.
Fusion Multi-media System (Bluetooth streaming & Airplay)
4 Channel Fusion Speaker Ready
Connection to selected vehicle steering wheel controls for sound/phone using CANbus
Connect RCA Reversing camera Input and up to 3 other RCA cameras
GARMIN DIGITAL SWITCHING MODULE
4 Configurable tank inputs, these are all voltage inputs only however via the use of a resistor you can convert your resistance-based sender to output a voltage signal, an example of this is in the inputs section of the manual.
1 channel dedicated for switch inputs from up to 6 physical momentary switches. These are multiplexed via the use of resistors, see the inputs section of the manual.
18 Outputs are fully configurable, each output can be assigned to one or multiple of the four different modes, each output can also be assigned to one or multiple of the 6 physical switches, the outputs can also be assigned to be dimmable (lights, fans) or non-dimmable outputs (TV’s, DC outlets etc.).
2 Outputs are permanently set to be non-configurable outputs, these are non- dimming and cannot be assigned to modes or physical switches.
Connects to Safiery CANbus BMS Lithium batteries directly CAN
Connects to Safiery Scotty, Scotty 1500 and Spock DC DC controllers directly
Connects to Safiery Touch Controller CAN
Connects to Safiery CANbus connected IP67 Rubberized Outdoor 8 button switch by CAN
Connects to Tyre Pressure Monitoring System (TPMS) by CAN
Connects to Light Intensity Sensor by RS485
Connects to Safiery digital tank level sensors (IP 67) by RS485
SAFIERY SOLO MODULE
Captures information from Victron system: VE.BUS, VE.DIRECT and VE.CAN devices by Ethernet
Sets Victron Inverters on/off/charger/inverter
Sets Inverter Charger AC Current Input Limit
Captures information from Ruuvi Bluetooth Wireless Pucks – up to 6
Connects to Tyre Pressure Monitoring System TPMS by CAN
Connects to Safiery Composting Toilet Automation by RS485
Connects to Safiery Automation of electric controlled Suspension Levelling System and manual Airbag control (check if air-suspension control system compatible) by RS485
Connects to digital Inclinometer and Airbag control by RS485
SAFIERY SUPER MODEM ROUTER WITH DIGITAL PROCESSOR
Connects IP Cameras – no limit but in practice 4 cameras suit connect by Cat5e
Connects Safiery Birds-Eye 4 Channel Processor with digital output connect by Special Cat 10 cable
Connects 4 IP67 cameras to Birds-Eye Processor by 4 wire AHD
Connects to Victron Cloud system giving users Victron Remote Management access by 4G
Connects to Remote Smartphone App for IP Camera viewing remotely
Connects IP camera system to App in Safiery Integrated Display using WiFi
span style="line-height:85%"><Safiery’s Integrated Display is the GARMIN 8 inch or 10 inch High resolution Display which can be mounted:
On a suction cup holder in vehicle with in-built power supply. Connects to Head Unit by WiFi
On the actual Head Unit magnetically attached and fitted in a double DIN slot in vehicle (LC79, Iveco, Mercedes and many others)
On a powered magnetic wall mounted base with in-built power supply. Connects to Head Unit by WiFi
Has a single “main use” graphic display with most used information and user defined modes for digital switching.
Has a vehicle or RV “Chassis level” display with pitch and roll, TPMS and air bag control
Has a “individual switch” display for each of the controlled outputs
Has a “Victron Inverter/Charger Control” display
Has a “User Customisation” display
It is licenced software; not available for sale as a separate software or a separate GARMIN system.
With a powerful choice of “mode” and “multi-device” switches, there is a user defined “Settings Page”.
On this page, the user selects which outputs are linked to the modes and 4 button switches.
<!--
Integrated Display Video
Integrated Display in OKA Video
-->
Full walk-through Video of Safiery Integrated Display in LC79 Coffee Truck
Full walk-through Video of Safiery Integrated Display
Garmin Navigation & HEMA Integration Video
When you purchase a Victron populated system togther with this item, we add the integration and change the screen to the one shown in the image above. There may be optional items shown above which are NOT included.
