Posted on 13/04/202513/04/2025 by NewAdmin2

Safiery’s Concrete eMixer has 2 year ROI with easy fleet retrofit – Lean and Green Australian technology.

Safiery’s hybrid retrofit system—featuring a 16kWh lithium battery, bidirectional motor generator (BMG), and Scotty AI controller

How is this possible?

Safiery’s new Permanent Magnet Generator controlled by Scotty AI V3 and Solid State Lithium technology provides the perfect power and energy sizing for electric driven concrete mixers while mixing, unloading and loading.
There is no need for 400V “over the top” solutions with excessive battery capacities.
This is a case of compact 48V power and lithium solutions that fit hand in glove.
We disrupt legacy solutions with lower capital costs resulting in higher ROI. Australian technology with a lean and green focus that can be exported to anywhere in the world.

Summary

Low-Cost Upgrade: Safiery’s hybrid solution integrates a 16kWh lithium battery and electric drum drive into the cement truck chassis for just AU$30,000 per unit. This retrofit offers immediate emissions and cost benefits without requiring full vehicle replacement.
Retains Hydraulic PTO drive: Safiery’s hybrid solution operate in parallel to the existing trucks PTO and hydraulic drive. It does not interfere with this. The truck at any time can revert to Diesel/PTO/Hydraulic Drives in unlikely event the battery power is depleted.
Substantial Fuel Savings: By using electric power during idling, loading, and unloading, diesel consumption can be reduced by 25–35%, translating to AU$6,750–AU$10,000 in annual fuel savings per truck under Australian urban conditions.
Substantial Oil and Maintenance Savings: By using electric power during idling, loading, and unloading, reduces DPF build up resulting in few oil changes and lower maintenance costs. Lower engine hours overall gives annual savings of $2,000 to $4,000 per truck under Australian urban conditions.
Rapid Payback: With combined savings in fuel, maintenance, and oil servicing, the hybrid investment pays for itself in 2–3 years.
Sustainability Compliance: The hybrid system supports net-zero goals by avoiding 20–30+ tonnes of CO₂ emissions per truck per year, aligning with Australia’s 2030/2050 emissions targets and Euro VI transition regulations.
Urban-Ready Deployment: Designed for stop-start city operations, the retrofit allows quiet, low-emission delivery in dense urban zones with no additional infrastructure or full vehicle downtime.

Feature	Safiery Retrofit	Liebherr /CIFA Hybrid
Power Source	16kWh + BMG	32kWh + plug-in charging
Charging Strategy	Engine-driven BMG	Plug-in charging only
Drum Drive	48V 90% efficiency	400V electric motor
Control System	Scotty AI	OEM proprietary
Retrofit Capability	Any diesel truck	Factory-integrated only
Price AUD	~$30,000	~$100,000 +
Battery Utilization	Energy-neutral	Discharge-only model
Daily Range	6–8 deliveries	Limited without
Daily Range	with net battery surplus	external charging

Metric	Safiery Retrofit	OEM Hybrids (Liebherr/CIFA)
Regenerative Braking	Yes, BMG	Yes, on some models
Vehicle Charging	Yes	No
Grid Dependency	None	High
Idle Emissions	Zero	Zero
Noise at Site	Very Low	Very Low
Installation Time	< 1-2 days	Factory only
Vehicle Downtime	Minimal	Requires new truck

Factor	Safiery	OEM Hybrids
Capital Cost	AU$30,000	AU$100,000+
Payback Time	2–3 years	6–10 years
Fleet Upgrade	Easy Retrofit	New truck only

Compelling Strategy

Safiery Advantage: Modular, retrofit-based, energy-neutral in daily use, and 1/3 the capital cost.
OEM Hybrid Limitation: Higher upfront cost, complex infrastructure, and limited regeneration.
Scotty AI Edge: Real-time SOC control and BMG optimization provide unmatched efficiency.

Posted on 11/04/202514/04/2025 by NewAdmin2

4WD Canopy Jupiter Series II with Solid State Lithium and Integrated STAR-Light 12 Channel Switching

Feature	Jupiter A	Jupiter B	Jupiter C	Jupiter D
	Series II	Series II	Series II	Series II
Lithium Battery Voltage	12V	12V	48V	48V
Switching and Control Voltage	12V	12V	12V	12V
DC DC	50A	50A	125A	125A can be upgraded to 250A
Replenishes 400Ah Lithium (12V equiv) in this time 20-100%	6.4 hours	6.4 Hours	2.5 Hours	1.2 Hours
Inverter	2000 VA	3000 VA	3000 VA	5000 VA
Integrated 240V AC Charging	1400 watts	2100 Watts	2100 Watts	3750 Watts
Solar MPPT Controller Panel Power	650 Watts	650 Watts	1100 Watts	1100 Watts
Smart Battery Protect	Yes	Yes	Integrated in Scotty	Integrated in Scotty
Digital Switching Channels	12 x 10A	12 x 10A	12 x 10A	12 x 10A
Dimmable Channels	8 x 10A	8 x 10A	8 x 10A	8 x 10A
RGBW Multi Colour Capable	Yes can have 2 x RGBW LED	Yes can have 2 x RGBW LED	Yes can have 2 x RGBW LED	Yes can have 2 x RGBW LED
Double Press to use one switch for dual colour LED's	Yes	Yes	Yes	Yes
Keypads included	1 x 8 button with indicating LED and backlit engravable	1 x 8 button with indicating LED and backlit engravable	1 x 8 button with indicating LED and backlit engravable	1 x 8 button with indicating LED and backlit engravable
Optional Keypads that can be added	Any number of wireless or CAN keypads. Up to 6 switches can switch on output	Any number of wireless or CAN keypads. Up to 6 switches can switch on output	Any number of wireless or CAN keypads. Up to 6 switches can switch on output	Any number of wireless or CAN keypads. Up to 6 switches can switch on output
Short-Circuit Protection on the STAR-Light circuits	Advanced protection activating within 80 microseconds	Advanced protection activating within 80 microseconds	Advanced protection activating within 80 microseconds	Advanced protection activating within 80 microseconds
Touch Screen Supported	5 in Victron Touch Screen	5 in Victron Touch Screen	5 in Victron Touch Screen	5 in Victron Touch Screen
Case Material	Stainless steel case	Stainless steel case	Stainless steel case	Stainless steel case
Physical Dimensions	750mm Long 750mm High 160mm wide	750mm Long 750mm High 160mm wide	750mm Long 750mm High 160mm wide	750mm Long 750mm High 160mm wide
240V In	240V Power in 15A	240V Power in 15A	240V Power in 15A	240V Power in 15A
240V out	Double GPO Out	Double GPO Out	Double GPO Out	Double GPO Out
USB	Dual USB incl Type C and Cig outlets	Dual USB incl Type C and Cig outlets	Dual USB incl Type C and Cig outlets	Dual USB incl Type C and Cig outlets
Anderson Out	2 Anderson Out: Compressor 50A Multiple Fridges 40A	2 Anderson Out: Compressor 50A Multiple Fridges 40A	2 Anderson Out: Compressor 50A Multiple Fridges 40A	2 Anderson Out: Compressor 50A Multiple Fridges 40A
Battery Connection	Amphenol Plug n play cable connections	Amphenol Plug n play cable connections	Amphenol Plug n play cable connections	Amphenol Plug n play cable connections
Solid State Battery Integration	CAN connection to Victron System No Shunt needed	CAN connection to Victron System No Shunt needed	CAN connection to Victron System No Shunt needed	CAN connection to Victron System No Shunt needed
Wireles Temperature Sensor Integration	Up to 8 blutooth pucks (optional purchase) can be added and see on screen	Up to 8 blutooth pucks (optional purchase) can be added and see on screen	Up to 8 blutooth pucks (optional purchase) can be added and see on screen	Up to 8 blutooth pucks (optional purchase) can be added and see on screen
Modem for hone visibility with Internet	Optional Modem available	Optional Modem available	Optional Modem available	Optional Modem available

Drop in and Start Using

Jupiter is pre-wired with all the inputs and outputs on the case.

The Photo shows a Jupiter D series I.

On the front panel are the power inputs and outputs with 5inch touch screen .

The GPO’s are ready to go as well as the 240V power in.

A certificate of compliance is issued so there is no need for an authorised electrcian at installation. We have taken care of that inside the case.

What's new in Series II

Series II has 2 major improvements.

The digital switching is upgraded to STAR-Light V2 with 12 channels of 10A switchable outputs .

Integration of the new Solid State Lithium batteries gives a screen view of the cell min/max and number of batteries on line and number of batteries charging/ discharging. Solid State Lithium is the safest lithium available. The Batteries are not included and are an optional extra.

The Victron Display shows the details of the batteries as they are compliant and compatible with Victron. You cant see this display with non-compliant lithium batteries.

4WD becomes Power Station for Caravan

Simply Plug in your caravan

Run the caravan from the 4WD as if you are on a powered site.

The length of time that you can operate for depends on the power load of the caravan and length of time. In our experience, here are typical times:
With 4 x Solid State in 4WD (850ah at 12V equiv) but generally 48V:

Aircon – 8 hours
All electric Kitchen – for 3-4 days

Safest Lithium Batteries Available with 10,000 Cycle Life

This battery will disrupt the lithium business because of it’s incredible safety and long cycle life of 10,000cycles.

It may well be that insurer’s will insist on this technology in the future as it significantly lessens their risk.

Safiery have fitted the same Victron and Marine compliant BMS that shows min/max cell voltages and temperature.

This is THE Ultimate in Lithium batteries.

420mm L x 250mm H x 150mm D about 20kgs

Solid State Lithium Battery 12V 217Ah 48V 53.7Ah Safest in Market 10,000 Cycles 2500W charge/Discharge

How Solid State is different to standard lithium

The traditional liquid lithium battery is called a ‘rocking chair battery’ by the scientific community because of its charging and discharging principle. The two ends of the rocking chair are the positive and negative poles of the battery, and the middle is the liquid electrolyte. Lithium electrons move back and forth across the two ends of the rocking chair and complete the charge and discharge of the battery during the process. In this process, there are many safety hazards: if there is overcharging, the battery is prone to heat, causing the electrolyte to swell, decompose, spontaneously ignite or even explode. The charging and discharging principle of a solid-state battery is the same as that of a liquid battery. The only difference is that its electrolyte is solid, which has many advantages over liquid electrolytes:

Benefits of Solid State Lithium

1) Higher Safety: The liquid electrolyte in traditional batteries creates safety hazards if over charging or electrical abuse. The result is thermal runaway and fire. Solid-state batteries have higher safety without this electroyte mass.

2) Higher Cycle Life: Because solid-state batteries use solid electrolytes, the cycle life is doubled. A minimum of 10,000 cycles at 80% depth of discharge is expected.

3) High energy density: As solid-state batteries use solid electrolytes, they do not need to use lithium-intercalated graphite anodes, but directly use metal lithium as the anode, which can reduce the amount of anode materials and increase the energy density of the entire battery.

4) Smaller size: The separator and electrolyte in the traditional liquid lithium battery account for nearly 25% of the entire battery mass. With the solid electrolyte, the distance between the positive and negative electrodes can be shortened to ten micrometers. The result is smaller battery dimensions and better quality control.

5) Lower temperature Range: Solid State Lithium is less affected by freezing temperatures because of the solid layers.

6) High Discharge rate:Solid State Batteries can discharge up to 10C. However, the BMS current rating limits discharge rates to 1C Continuous and 2C for 10 secs.

Safety Specification of Solid State Lithium

SAFETY SPECIFICATION

CAN BE CHARGED AT TWICE NORMAL VOLTAGE
CAN BE SHORT CIRCUIT FOR EXTENDED 60 MINS
CAN SUSTAIN HEAT TO 130C
CAN BE CRUSHED TO 200KN
CAN BE PENETRATED BY 8mm NAIL at 25mm/s

Stackable Batteries with concealed Interconnection Strap

Nail Penetration test Solid State Lithium by University College London September 2024

STAR-Light Digital Switching

STAR-Light has 12 Channels to switch.

See the suggested list in the image on the right.

The Dual colour channels can be controlled by a single button.

For example the Work Light Driver and Passenger can be controlled with a single button: “Work Lights”.
Press for Passenger side, Double Press for Drivers side, Press again for both to come on.

This way, 12 outputs can be controlled by a single 8 button keypad.

Choice of 4 different keypads

Included in Jupiter Pack is the rubberised 8 button keypad. It has such a nice traditional button press but your fingers can be grimy or dripping inoil ad they clean up easily.

As an option to add are the choice of Engravable CAN or Battery operated long range bluetooth for the drivers side Or our new interchangeable icon keypad (optional extra)

STAR Range of Powerful SWITCHING -yet so SIMPLE to Use

Customers wanted a digital switching system that is so easy to install. Everyone wanted to operate only with switches, others touch screens and then others to use a phone app. Safiery have all these forms of control. The simplicity is that all these communication paths go directly to the STAR controller. This reduces the cost to make STAR Range around half the cost per output to the published retail price of Redarc equialent.

Digital Switching STAR-Light double press single button to change colour White

Digital Switching STAR-Light double press single button to change colour Amber

STARSHIP Controllers and Switches

Cyber Blockchain Encryption is baked into every STARSHIP controller.

Comparison of STAR-Light and Redarc Rogue

Feature	STAR-Light V2	TVMS Rogue
Channels	12x 10A dimmable channels	10x 10A dimmable outputs
Maximum Output Current	40A (total for all channels)	40A (total for all channels)
Switch Styles	CAN wired 8 or 12 button, wireless 4 button	None, individual switches (not supplied) have to be wired in. No Wireless
Short-Circuit Protection	Advanced protection activating within 80 microseconds	On-board smart fuses – activation time not specified
Integration	Integrates with STAR-Touch 7in screen and Victron power system	Pairs with Manager30 battery management system and RedVision display
Dimming LEDS	Yes 8 channels Dimmable	Yes 10 channels Dimmable
RGBW Multi-colour LED	Yes up to 2 x RGBW Leds	No Multi-colour not possible
White Amber LED Switching	Yes Dual colour lights can be alternately switched from the one switch with a double press	No not possible
Case Material	All Alloy anodized	Plastic
Physical Dimensions	120mm x 90mm x 30mm	250mm x 130mm x 25mm
Operating Voltage	12V	12V
Temperature Range	-20°C to 70°C	-20°C to 70°C
Touch Screen Supported	7 inch Touch Screen WiFi Wireless also integrates with Victron range and STAR-Tank Bluetooth Wireless (up to 5 tanks)	RedVision screen, or mobile app via Bluetooth, up to 2 tanks supported
Additional Features	Long-range Bluetooth connectivity tested up to 40 meters with some metal obstruction	Ignition input.

Tank Measurement made easy with Optional STAR-Tank (not included in Jupiter Packs)

Tank measurement can be so troublesome. If you have a jack-off canopy, then even more so. This is why we developed a bluetooth battery operated radar tank level sensor.
It communicates directly with Victron Cerbo or if you dont have a Victron System then see it on the STAR-Touch 7 inch Display when you combin with STAR-Power.

Victron Dark Display with 4 STAR Tank Showing

STAR-Tank Battery Operate Bluetooth

35m Range test of STAR-tank Battery Bluetooth links Victron GX black, grey, fresh water tanks

Optional Double Induction - No Pulsing - not included in Jupiter Packs

Induction Cooking is fast and efficient:

Induction cooking is 94% efficient. Compare to LPG at 40%.
No need to clean the bottom of pot
Now with precise control and smooth power dimming from as low as 400W.
1800W front Element and 1500W Rear Element
Does not overload Inverter: Select Size 2000W or 3000W

Double Induction Cooking fresh Salmon

Double Induction Installed inside SLRV Camper

ARB LPG Drawer removed for Safiery Double Induction on VW Transporter Lithium Solar

ALTERNATOR POWERED GYRO’s FOR 24/7 OPERATION

ALTERNATOR POWERED
GYRO’s FOR 24/7 OPERATION
